High Temperature Vacuum Sintering Furnace
The high-temperature vacuum sintering furnace shell and vacuum pipe are welded by CNC automatic welding machine. The weld seam is smooth and smooth without sand inclusions in welding.
- Product Introduction
Product description:
1. The high-temperature vacuum sintering furnace shell and vacuum pipe are welded by CNC automatic welding machine. The weld seam is smooth and smooth without sand inclusions in welding. It is guaranteed to meet the technical standard of no welding defects after ultrasonic flaw detection.
2. The equipment is equipped with a 15-minute UPS uninterruptible power supply for emergency use of the system operation in case of a sudden power failure, such as closing the vacuum valve.
3. PLC is a special customized PLC, with 14-bit analog-to-digital and digital-to-analog conversion chips, and user program area: 16K. Temperature transmitter 2‰ class.
4. Highly integrated quick-connect electrical connection is convenient for equipment relocation. After passing the factory inspection, all pipelines and cables have been connected, and only need to be plugged in when debugging, so the installation is convenient, the debugging cycle is short, and the success rate of one-time debugging 100% error-free.
5. The center hole of the press bracket is precisely machined by the machining center to ensure that the movement deviation of the pressure head is smaller during pressurization, and the displacement change display accuracy can reach ±0.02mm.
6. The equipment has the functions of automatic pressurization, automatic pressure stabilization and pressure maintenance during pressurized sintering. The imported pressure regulator has reliable performance and is equipped with a speed regulating valve to adjust the pressurization speed. And it has pressure fluctuation ≤ ± 1%, digital signal output, strong anti-interference.
7. The standard electric control cabinet is safer to use and more convenient to operate; the main electrical components of Omron or Schneider brand are reliable in quality and stable in control; the system has a classified sound and light alarm function, which is easy to judge the cause of failure.
Equipment composition:
The high temperature vacuum sintering furnace is mainly composed of the following parts: furnace body, furnace cover, heating element, heat shield, temperature measurement system, temperature control system, transformer, vacuum/gas system, pressurization system, water circulation distribution system, etc.
Main technical parameters:
Maximum temperature: 2100°C
Pressure range: 10-800T
Heating method: graphite
Vacuum degree: 6×10-3Pa
Effective working area: customizable
