New Developed Multi Chamber Continuous Vacuum Furnace
New developed Multi chamber continuous vacuum furnace is a state-of-the-art technology, which has revolutionized the metallurgical industry.
- Product Introduction
At present, most enterprises use single or double chamber intermittent vacuum furnaces, which have the disadvantages of low efficiency, high energy consumption, high cost, small output, and are not suitable for large scale production. In order to overcome the above-mentioned shortcomings of intermittent vacuum furnaces and meet the needs of modern industrial mass production, new developed multi chamber continuous vacuum furnace has been developed based on single chamber and double chamber intermittent vacuum furnaces. This product is a fully automatic assembly line type multi chamber combined electromechanical integrated vacuum heating equipment. Its structure is novel, operation is simple, performance is advanced, and operation is reliable. The overall technical performance of new developed multi chamber continuous vacuum furnace has reached the same level as similar products in developed countries. It is an ideal equipment for upgrading and replacing traditional single chamber intermittent vacuum furnaces.
New developed Multi chamber continuous vacuum furnace consists of a feeding chamber, a preheating chamber, a high-temperature working chamber, a cooling chamber, a discharge chamber, an intermediate gate valve, a vacuum system, a workpiece transfer system, a water cooling system, an electrical control system, and other parts. Due to the use of modular design, production lines of different sizes such as seven room, five room, and three room can be freely combined according to user needs to meet the production needs of different sizes.
| Main data parameters of Industrial Vacuum Continuous Furnace | ||||||
|
Model |
Average temperature zone size |
Maximum temperature |
Ultimate pressure |
Pressure rise rate |
Temperature uniformity |
Loading volume |
|
RVSQ-224 |
250×250×400 |
1300 |
4×10-1 |
0.5 |
±5 |
50 |
|
RVSQ-335 |
300×300×500 |
1300 |
4×10-1 |
0.5 |
±5 |
100 |
|
RVSQ-446 |
400×450×600 |
1300 |
4×10-1 |
0.5 |
±5 |
200 |
|
RVSQ-558 |
500×500×800 |
1300 |
4×10-1 |
0.5 |
±5 |
300 |
|
RVSQ-669 |
600×600×900 |
1300 |
4×10-1 |
0.5 |
±5 |
500 |
|
RVSQ-7710 |
700×700×1000 |
1300 |
4×10-1 |
0.5 |
±5 |
800 |
|
RVSQ-8812 |
800×800×1200 |
1300 |
4×10-1 |
0.5 |
±5 |
1200 |
|
RVSQ-70×11 |
Φ700×1100 |
1300 |
4×10-1 |
0.5 |
±5 |
800 |
Advantages of Industrial Vacuum Continuous Furnace
High degree of integration of mechanical and electrical. On the basis of the improvement of temperature measurement and control accuracy, the workpiece movement, air pressure regulation, power adjustment can be programmed in advance, and quenching and tempering are carried out according to the steps.
Energy consumption is lower than salt bath furnace. Modern advanced vacuum industrial furnace heating chamber is made of high quality heat insulation material and wall, which can concentrate electric heating energy into heating chamber with remarkable energy saving effect.
The accuracy of furnace temperature measurement and monitoring is obviously improved. The indicating temperature of the thermocouple and the temperature of the furnace reach 1.5 C. But there is a large temperature difference in a large number of workpieces in different parts of the furnace. If the forced circulation of the rarefied gas is adopted, the temperature range of the temperature range of + 5 DEG C can still be controlled.
No pollution to the environment, no need for three wastes treatment.
The utility model can completely eliminate the oxidation and decarburization of the workpiece surface in the heating process, and can obtain clean surfaces without deterioration layers. For cutting tools that grind only one side of grinding (such as twist grinding, the surface of the groove surface is exposed to the blade directly), the cutting performance is greatly improved.
Industrial Vacuum Continuous Furnace Manufacturer – Shenyang Hengjin Machinery
Shenyang Hengjin Machinery has engaged in Vacuum Heat Treatment Furnace research and manufacturing. We have received a lot of good feedback about the Vacuum continuous furnace from our customers. It plays an sequential treatment of a large number of parts or materials without interruption. In addition to the debinding and sintering furnace, we provide vacuum brazing oven, vacuum gas quenching furnace, vacuum tempering furnace, vacuum annealing furnace, vacuum heat treating furnace, high temperature vacuum furnace, vacuum brazing furnace, vacuum oil quench furnace, Hengjin Vacuum Continuous Furnace, high temperature vacuum sintering furnace, brazing vacuum furnace,and so on.
