High Quality Brazing Vacuum Furnace
High quality brazing vacuum furnace is a device used for heating and connecting metal parts. It uses vacuum technology to achieve a low-pressure or even vacuum state of the atmosphere inside the furnace, thereby preventing impurities and pollution caused by oxygen and ensuring the quality and reliability of welding.
- Product Introduction
High quality brazing vacuum furnace is a high-temperature industrial equipment mainly used for brazing metal products of different materials. Its main characteristics are high temperature, high sealing, and high precision. In industrial production, vacuum brazing furnaces have a wide range of applications, mainly in the following aspects:
1. Chemical industry. In industries such as petroleum, chemical, and energy, a large number of equipment made of different materials, as well as various chemical catalysts, are used. High quality brazing vacuum furnace can effectively connect and weld these different materials.
2. Electronics industry. In the electronics industry, high precision circuit boards are required for various electronic products. High quality Vacuum brazing furnaces can help solder small components on circuit boards, avoiding loosening of components or poor contact of various circuits.
3. Mechanical manufacturing field. In the field of mechanical manufacturing, vacuum brazing furnaces can be used to manufacture high-precision mechanical components, avoiding problems such as component failure and cracking caused by poor connections.
Overall, high quality brazing vacuum furnace are mainly used for high-temperature connection and welding in various industries, with characteristics such as high precision, high efficiency, and high reliability, which are conducive to improving production efficiency and product quality.
At the same time, vacuum brazing furnace are safer, more stable, have a longer lifespan, and are more environmentally friendly than ordinary welding equipment. Therefore, using a vacuum brazing furnace can greatly improve work efficiency and quality, and is also a sustainable and environmentally friendly technology.
|
Main data parameters of high temperature vacuum brazing furnace |
|||||
|
Model |
Average temperature zone size |
Maximum temperature |
Ultimate pressure |
Pressure rise rate |
Temperature uniformity |
|
RVSB-459 |
450×450×900 |
1300 |
8.5×10-4 |
0.5 |
±3 |
|
RVSB-559 |
500×500×900 |
1300 |
8.5×10-4 |
0.5 |
±3 |
|
RVSB-669 |
600×600×900 |
1300 |
8.5×10-4 |
0.5 |
±3 |
|
RVSB-6612 |
600×600×1100 |
1300 |
8.5×10-4 |
0.5 |
±3 |
|
RVSB-7712 |
700×700×1200 |
1300 |
8.5×10-4 |
0.5 |
±5 |
|
RVSB-8716 |
800×700×1600 |
1300 |
8.5×10-4 |
0.5 |
±5 |
Company profile:
Shenyang Hengjin, established in 2000, is a technology-based joint-stock enterprise specializing in the research, development and manufacture of vacuum equipment. The company is located in a national development zone, has independent intellectual property rights, and is a national high-tech enterprise. Has 28 patents and various enterprise honor certifications.
Hot Tags: high quality brazing vacuum furnace, China high quality brazing vacuum furnace manufacturers, suppliers, factory
